Piping Engineering Deliverables The piping engineering disciplines is responsible for the following deliverables. Different organizations and different regions of the world may use alternate terminologies or prepare additional deliverables depending on the scale of the project which are inlcluded in the brackets:
- Plot Plans (Overall Plot Plan and Unit Plot Plans)
- Equipment Layouts
- Piping General Arrangement Drawings (Piping Plans or Piping GADS)
- Piping Section and Details (Usually included as part of Piping Plans)
- Conceptual Piping Layouts or Study Piping Layouts
- Piping Isometrics
- Line Designation Table (Line List or Line schedule)
- Tie-in Schedule (Tie-in Index) Nozzle Orientation Drawings
- Piping Demolition Drawings
- Pipe Support Details
- Material Take Off (Bill of Material or MTO in short)
- Piping Material Classes
- Piping Specifications
- Speciality Items List
- Data Sheets for Valves
- Data Sheets for Piping Specials
- Technical Bid Evaluation
- Piping stress analysis report
- 3D Model
